This product model is a 5kN thrust single-shaft turbojet engine developed based on the mature manufacturing technology and practical application of XX850 core engine.It features a broader flight envelope, lower fuel‑consumption rate and simpler operation & maintenance compared with domestic peer products of equivalent weight class.

Application Fields

Low Cost Attritable UCAVs, Next Generation Loyal Wingmen, Target Drones, Cruise Missiles

850kgf Turbojet Engine（Core Engine）

This single‑shaft small turbojet engine features long service life, simple structure and low cost, with great potential for derivative development. Custom low‑cost and high‑power‑extraction variants are available.Highly mature and cost‑effective, it is China’s first design‑qualified 10 kN‑thrust aero‑engine equipped with FADEC system. It has undergone flight tests and technical qualification onboard WL‑10, China’s first high‑altitude high‑speed large export‑oriented UAV. Another new‑generation UAV fitted with this engine has also completed its maiden flight.

Application Fields

High‑altitude strategic UAVs, Unmanned Combat Aerial Vehicles (UCAVs)

1000kgf Turbojet Engine

Developed from the XX850 core engine, this 10 kN‑thrust turbojet delivers higher thrust‑to‑weight ratio, lower fuel consumption, enhanced electric power extraction and lower cost per unit thrust versus its prototype.

Application Fields

Low‑cost attritable UCAVs, next‑generation loyal wingmen, target drones, cruise missiles

1000kgf Turbofan Engine

Built on proven manufacturing and application experience of the XX850 engine, this single‑shaft 10 kN‑thrust turbofan achieves substantially increased thrust and reduced fuel consumption compared with its prototype.

Application Fields

Large high‑altitude UAVs, small‑and‑medium‑size UCAVs, loyal wingmen

1300kgf Turbofan Engine

Developed from the XX850 core engine, this single‑rotor low‑bypass‑ratio turbofan adopts an all‑electric design with strong adaptability and balanced overall performance.

Application Fields

Large high‑altitude UAVs, loyal wingmen, UCAVs, supersonic UAVs

1MW Gas Turbine（Power‑Family Derivatives）

Leveraging proven manufacturing and application of the XX850 engine, this fully domestic megawatt class gas‑turbine gas generator is developed via independent derivative design. It features mature technology, compact size, light weight and easy maintenance.Matched with power turbine and generator, it forms a 1 MW gas‑turbine generator set, characterized by adaptability to frigid and high‑altitude conditions, fast start‑up and high mobility. Integrated with flue‑gas heating‑cooling units, it builds a megawatt‑scale combined cooling, heating and power (CCHP) system.

Application Fields

Widely deployed for civil, military and industrial sectors； Typical scenarios: emergency power supply, standby power supply, industrial waste‑heat power stations, military power‑generation equipment, and distributed energy for CCHP.

Aero‑Power Systems – Genealogical Development Centered on One Core Engine

Guided by prime‑unit requirements and built upon a proven core engine, ZFTX pursues iterative upgrades and derivative genealogical development. It develops light‑duty turbojet/turbofan engines with thrust below 2000 kg, providing full‑range power solutions and services for UAVs, business jets and cruise missiles worldwide.

--------------------------------

High Performance

——

· High‑altitude operation

· Wide operating envelope

· Advanced control system

· High reliability

· Strong shock and overload resistance

Low Cost

——

· Compact structure

· Proven technology

· Easy maintenance

· Full IP rights

· Fully‑domestic supply chain

· Mature accessories, stable quality

100% Indepentent&Controllable

——

· Multi‑thrust coverage · Unified interfaces, high compatibility · Large life‑extension potential

Easy to upgrade&adapt

——

--------------------------------

Family‑Product Advantages

Megawatt‑class Gas Turbine

Megawatt‑class Gas‑turbine CCHP Unit

This skid‑mounted integrated unit adopts self‑developed derivative megawatt‑class gas turbine, delivering high power‑to‑weight ratio, rapid startup, strong environmental adaptability and wide fuel compatibility. It supplies ≥1000 kW power, supporting liquid fuels (diesel, aviation kerosene) and gaseous fuels (natural gas, associated petroleum gas). Output: 380V/220V, 50Hz for direct equipment use. As mobile emergency & standby power source, it supports major events, disaster rescue, emergency command, large venues and industrial parks. It provides energy for offshore platforms, islands, oilfields, mining, geological exploration, field operations and border defense camps. It also generates power with industrial combustible process gas and associated petroleum gas to realize waste‑heat recovery and low‑carbon operation.

Derived from XX850‑based megawatt‑class gas generator and matched with power turbine, this compact gas turbine achieves rated output ≥1000 kW. It features high power density, fast startup and strong environmental adaptability with good maintainability. It can form gas‑turbine generator sets and CCHP distributed energy systems, and power special equipment and small vessels.

Combining megawatt‑class gas‑turbine generator set with waste‑heat flue‑gas unit, this CCHP system recovers high‑temperature exhaust heat. While generating electricity, it provides megawatt‑grade heating, cooling and domestic hot water, with high energy efficiency, good mobility and strong environmental adaptability. With container‑style skid‑mount design, it acts as multi‑domain distributed energy system.

CCHP | Combined Cooling Heating and Power

Megawatt‑class Gas‑Turbine CCHP Technology

Jointly awarded a national key project with Beihang University

——100% domestically‑sourced core power system

Megawatt‑Class Gas Turbine Energy System

Modified from proven lightweight aero‑engine technologies and applications, this megawatt‑class ground gas turbine integrates serial megawatt generator sets and CCHP systems. It serves civil, military and industrial sectors to satisfy multi‑scenario demands for power, heating and cooling.

Megawatt‑class Gas‑turbine Generator Set
